Roxtone DMX001 Cable (per meter)
₱63.00
Tax included.
₱63 per meter of cable
(ex. 9 meter x 63 = ₱567)
Features
• Optimum shielding with dense copper spiral shielding + AL/PT-foil
• Small diameter, thus suitable for use with RCA-connectors
• Very reasonable price
Applications
• Studio patch cabling
• Control of lighting, scanner units, and displays
• Permanent installation
Cable Colour
• Black
• Blue
|
Technical Data |
|
|
Jacket, diameter |
PVC 5.2 mm |
|
AWG |
24 |
|
No. of inner conductors |
2 x 0.22 mm² |
|
Copper strand per conductor |
7 x 0.20 mm |
|
Conductor insulation |
PE 1.70 mm |
|
Drain Wire |
Tin plated copper 10 x 0.15 mm |
|
Shielding |
Copper spiral shielding with 80 x 0.10 mm + AL/PT-foil+PE filler |
|
Shielding factor |
100 % |
|
Temperature range |
min. -20 °C |
|
Temperature range |
max. +70 °C |
|
Packaging |
100/300 m roll |
|
Electrical Data |
|
|
Capac. cond./cond. per 1 m |
43 pF |
|
Capac. cond./shield. per 1 m |
104 pF |
|
Cond. resistance per 1 m |
82 mΩ |
|
Shield. resistance per 1 m |
23 mΩ |
