Blackmagic Design HyperDeck Studio HD Plus

Key Features:


Records up to 4K DCI at 30 fps
Plays Back up to 3840 x 2160 at 30 fps
1 x 6G-SDI Input, 1 x HDMI 2.0 Input
1 x HDMI 2.0 and 2 x 6G-SDI Outputs
Records ProRes, DNxHD, and H.264
Records in H.264 SDI 4:2:2 10-Bit
Front-Panel Buttons, Jog Wheel, LCD
Timecode and Reference Input/Output
1/2 Rack-Mountable Form Factor
USB-C, 1G Ethernet, RS-422



Take a compact broadcast-quality record/playback deck with you on location, in the studio, or built into a rack with the Blackmagic Design HyperDeck Studio HD Plus. The 1 RU tall recorder is 1/2 of a rack wide and powers from 100 to 240 VAC or via an optional 12 VDC power supply for portability. Featuring one 6G-SDI input, one HDMI 2.0 input, two 6G-SDI outputs, and one HDMI 2.0 output, this unit is a compact recording/playout powerhouse. A loop-through output and 3G-SDI monitor output as well as reference and timecode in/out, allow this device to fit into a broadcast environment.
